Below is a tutorial on modulation transfer functions (MTF) and how to measure the MTF of an optical system.

The modular transfer function (MTF) is a measure of contrast versus spatial frequency.  Full contrast, 100%, is an unattenuated pattern of a given spatial frequency or line pair.  The MTF plot is typically normalized at 1 or 100% unattenuated contrast (vertical axis), while the horizontal axis is the dependent variable spatial frequency normally in units of lines/mm.  The figure below gives an illustration of how the image degrades with decreasing contrast




website statistics
LOD Publications
LOD Examples of Previous Work
Contact Information:

       Owners: Dr. Logan DesAutels and Kristen DesAutels

       Phone: (937) 469-0756
       Logan's Email: ld@loganopticaldesigns.com







Figure 1: Image of degrading line pairs with decreasing contrast.


The next figure shows a MTF chart for a typical system.



















Figure 2: This is a MTF plot showing the MTF for each field angle (0░, 20░, -20░).



The MTF figure shows a fairly straight black line (top line), which represents a diffraction limited or ideal design MTF performance.  Due to diffraction, from light scraping on the lens limiting aperture, there is limited contrast performance that is resolvable - as is observed, the maximum/best resolvable contrast for 200 lines per mm is 30%, and the real contrast gives only ~5% contrast for 200 lines per mm.


A good criterion for excellent optical performance for different camera applications is given:
1.        Motion picture camera lenses - 50% MTF at 50 lpm.
2.        35-mm camera lenses - 20% MTF at 30 lpm over the whole field (FOV).
3.        35-mm camera lens on axis - 50% MTF at 30 lpm.
4.        Additional aberration criterion for common camera lenses:
a.        Distortion <2%.
b.        Optical Path Difference (OPD) < 2 waves.
c.        Ray Fan < 50Ám.
